Eaton (Installation) Fire protection switch 2-pole, B10A, 30mA AFDD-10/2/B/003-A NEW

Item condition: New and in original packaging

Manufacturers: Eaton#
EAN: 4015081822171
Heiz24 article number: SP5711560
TARIC: 85362010
Country of origin: CZ
Category: Sicherungsautomaten, SHL,FI und sonst. Einbaugeräte

€ 169,65

incl. 19% VAT , Free shipping to DE.

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

10 Pcs. in the supplier warehouse

Estimated delivery time (may vary): 3 - 5 workdays (DE - foreign countries differ)

more than 10 Pcs. we can order for you

Pcs.

High-quality fire protection switch (arc-fault protective device) with residual current circuit breaker/line circuit breaker combination, mains-voltage-independent, contact position indicator red - green, terminal backplane protection, tristable latching slide - enables removal from an existing busbar system, extensive range of accessories can be retrofitted, large selection of rated residual currents, rated currents up to 40 A, tripping characteristics B, C, D, rated breaking capacity 10 kA, suitable for outdoor use (construction and outdoor distribution boards) up to -25 °C

Item information	Value
Protection class (IP):	IP20
Number of poles:	2
Width in units of division:	3
Frequency:	50 Hz
Rated voltage:	230 V
Installation depth:	67 mm
Rated current:	10 A
Release characteristics:	B
Pollution level:	2
Overvoltage category:	3
Energy limitation class:	3
Switching neutral conductor:	nein
Rated residual current:	0,03 A
Residual current type:	A
Rated breaking capacity according to EN 61009:	10 kA
Rated breaking capacity according to IEC 60947-2:	0 kA
Rated switching current Auxiliary device:	0 A
Rated voltage auxiliary device:	230 V
Control voltage type Auxiliary device:	AC
Additional equipment fitted at the factory:	Brandschutzschalter
Shipping weight:	0,30 kg
Item weight:	0,28 kg
Dimensions ( Length × Width × Height ):	5,50 × 8,60 × 7,50 cm
