ABB Stotz S&J Transformer Meter M-Bus A44 213-100 NEW

Item condition: New and in original packaging

Manufacturers: ABB
EAN: 7392696705356
Heiz24 article number: SP5709012
TARIC: 90283019
Country of origin: IT
Category: Sicherungsautomaten, SHL,FI und sonst. Einbaugeräte

€ 768,55

incl. 19% VAT , Free shipping to DE.

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

Pcs.

Three-phase meter for measuring a three-wire or four-wire three-phase network via a CTVT transformer connection (configurable transformer ratio for current and voltage) up to a maximum of 6 A. The following values are output via a white backlit display with up to 7 digits: Active energy (class 1) and reactive energy (class 2) for import and export, powers, currents, voltages (L-L, L-N), frequency, cos phi, power factor and apparent power, both per phase and total. Communication can take place via the integrated M-Bus interface or via the infrared interface for connecting a KNX module. The energy meter has one output. This can be used either as a pulse output for outputting the active or reactive energy or as an alarm output. Up to 25 alarm values (threshold values with time delay) can be set here. The meter is calibrated according to MID and approved according to IEC. The installation width is 7 DIN modules.

Item information	Value
Version:	Messwandler
Suitable for:	Bezug Bezug/Lieferung
Protection class (IP):	IP20
Height:	97 mm 26,5 mm
Mounting type:	REG
Width in units of division:	7
Display type:	digital
Accuracy class:	B
Backstop:	Ja
Wide:	123 mm
Depth:	65 mm
Frequency:	50..60 Hz
Protection class (NEMA):	sonstige
Rated current (In):	6 A 1 A
Calibrated:	ja
Execution of the interface:	M-Bus
Number of posts:	7
EDL40 signature:	nein
Energy type:	Wirk- und Blindleistung
Pulse type:	S0
Pulse output:	elektrisch
Pulse rate:	1..999999 Imp/kWh (kvarh)
Maximum current (Imax):	6 A
Measurement type Load profile:	nein
With lock code:	nein
Rated voltage (Un) N-L:	57,7..288 V
Polart:	Vierleiter
Tariff version:	Eintarif
Counter type:	elektronisch
Approval:	Measuring Instruments Directive
Rated voltage (Un) L-L:	100..500 V
Shipping weight:	0,45 kg
Item weight:	0,36 kg
Dimensions ( Length × Width × Height ):	14,40 × 9,80 × 6,80 cm
