Theben Theben digital room thermostat RAM 746 RA 746 0 131 NEW

"Fig. similar. , errors in texts and images excepted."

Theben Theben digital room thermostat RAM 746 RA 746 0 131 NEW

Item condition: New and in original packaging

Manufacturers: Theben#
EAN: 4003468746035
Heiz24 article number: WS6001516
TARIC: 90321020
Country of origin: DE
Category: Regulations

€ 88,30

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

Pcs.

Function:
Room thermostat with thermal feedback for installation in flush-mounted boxes. Ideal controller for modernisation and new builds, as it can be easily integrated and therefore fits seamlessly into the home environment.
- Setting range +5 °C to +30 °C
- Temperature range can be limited under the setting knob
- Simple connection thanks to screwless terminals
- Available as a replacement device without frame, cover plate and setting knob, incl. building protection cap - Frame, centre plate and setting knob available as accessories. Protective cap
- Frame, centre plate and setting knob available as accessories
- Centre plate fits into almost any frame using the switch manufacturer's adapter frame

RAM 741 RA
- Normally closed contact

RAM 746 RA
- Normally closed contact
- Integrated temperature reduction (approx. 4 K) possible via external control (e.g. timer)
- Switch for heating ON/OFF + indicator lamp

RAM 748 RA
- Changeover contact for heating or cooling Cooling

Scope of delivery:
- Room temperature controller
- Frame
- Cover plate
- Control knob
Technical data:
Operating voltage:
230-240 V~, +10 %/-15 %, 50-60 Hz
Normally closed contact:
10 (4) A, 230 V~
max. 10 THEBEN actuators can be controlled
Changeover contact:
10 (4) A (heating),
max. 10 THEBEN actuators can be controlled,
5 (1) A (cooling)
Temperature range: +5 °C... +30 °C
Switching differential, dynamic:
approx. 0.5 K, thermal feedback
Electrical connection:
screwless terminals for 2 x
(1.5 mm2-2.5 mm2) wire
Protection class:
II to EN 60 730-1 when installed as intended

Protection class:
IP 30 to EN 60 529 (with cover, built-in)
Housing colour: pure white glossy (RAL 9010)

Test mark: VDE

PDF

60_015_14--DBL-01-de.pdf

Datenblatt

60_015_14--DBL-01-de.pdf

60_015_16--DBL-01-fr.pdf

Datenblatt

60_015_16--DBL-01-fr.pdf

Item information	Value
Type:	RAM 746 RA
Brand:	theben®
EAN:	4003468746035
Version:	An/Aus
Operation:	Dreh
Colour:	grau
Width [mm]:	80,5
Height [mm]:	80,5
Protection class (IP):	IP30
Connection:	4-/5 Leiter
Depth [mm]:	24,5
Manufacturer no.:	746 0 131
Mounting type:	Unterputz
With display:
Contact:	1 Öffner
Rated current at 230V~:	10 (4) A
Shipping weight:	0,11 kg
Item weight:	0,10 kg
Dimensions ( Length × Width × Height ):	8,80 × 8,60 × 4,60 cm
LaNr.:	60 015 16
