| Surface protection: |
pulverbeschichtet |
| Protection class (IP): |
IP66 |
| Illuminant: |
LED nicht austauschbar |
| With illuminant: |
Ja |
| Housing colour: |
grau |
| Enclosure material: |
Aluminium |
| Light colour: |
weiß |
| Suitable for number of lamps: |
40 |
| Voltage type: |
AC |
| Control gear: |
LED-Betriebsgerät stromgesteuert |
| With control gear: |
Ja |
| Without dimming function: |
Ja |
| Dimming DALI: |
nein |
| Light emission: |
direkt |
| Protection class: |
I |
| Colour rendering index CRI: |
70-79 |
| Connection type: |
Schneidklemme IDC |
| Rated voltage: |
220..240 V |
| Version: |
ohne |
| Suitable for wall mounting: |
Ja |
| Suitable for ceiling mounting: |
nein |
| Suitable for recessed mounting: |
nein |
| Suitable for surface mounting: |
Ja |
| With motion detector: |
nein |
| Number of poles: |
3 |
| Cover material: |
Glas transparent |
| Suitable for pendulum suspension: |
nein |
| Suitable for VDU workstations according to EN 12464-1: |
Ja |
| Dimming DMX: |
nein |
| Dimming Mains voltage modulation: |
nein |
| Dimming phase section: |
nein |
| Dimming phase angle control: |
nein |
| With light sensor: |
nein |
| Impact resistance: |
IK08 |
| Adjustability: |
schwenkbar |
| Wide: |
265 mm |
| Length: |
340,5 mm |
| Power factor: |
0,98999999 |
| Conductor cross-section: |
1,5 mm² |
| Suitable for lamp wattage: |
93 W |
| Connectable conductor cross-section: |
7..14 mm² |
| Brushed surface: |
ja |
| IFTTT support available: |
nein |
| Compatible with Amazon Alexa: |
nein |
| Compatible with Apple HomeKit: |
nein |
| Compatible with Google Assistant: |
nein |
| Radiation angle: |
breitstrahlend 41-80° |
| Luminous flux: |
12000 lm |
| Colour temperature: |
4000 K |
| Dimming 1-10 V: |
nein |
| Dimming DSI: |
nein |
| Dimming manufacturer-specific: |
nein |
| Dimming with push-button: |
nein |
| Dimming Touch and Dim: |
nein |
| Dimming 0-10 V: |
nein |
| Dimming GPRS: |
nein |
| Dimming LineSwitch: |
nein |
| Dimming potentiometer (device-integrated): |
nein |
| Dimming programmable: |
nein |
| Dimming RF: |
nein |
| Dimming Sine Wave Reduction: |
nein |
| Dimming Zigbee: |
nein |
| Energy efficiency class of the light source according to EU regulation 2019/2015: |
nicht relevant |
| Light distribution: |
asymmetrisch |
| Wiring type: |
Abschluss |
| Radiation angle adjustable: |
nein |
| Replaceable control gear: |
ja |
| Rated luminous flux according to IEC 62722-2-1: |
12000 lm |
| Rated ambient temperature according to IEC62722-2-1: |
-40..35 °C |
| Colour consistency (McAdam ellipse): |
SDCM3 |
| Colour temperature adjustable: |
nein |
| Glow wire test according to IEC 60695-2-11: |
650 °C - 30 s |
| Height/depth: |
67,4 mm |
| Constant luminous flux control: |
nein |
| Luminaire with limited surface temperature "D-sign: |
nein |
| Luminous efficacy: |
126 lm/W |
| Luminous flux adjustable: |
stufenlos |
| Light distributor: |
Diffusorlinse/-optik/-panel |
| Max. Number of luminaires Circuit breaker B16: |
8 |
| Max. Number of luminaires Circuit breaker C16: |
13 |
| Max. System performance: |
98 W |
| Emergency power supply integrated: |
nein |
| Reflector: |
ohne |
| Photobiological safety according to EN 62471: |
RG1 |
| Light intensity: |
861 cd |
| Covering of the luminaire with thermal insulation material possible: |
nein |
| Dimming depending on the control gear: |
nein |
| Dimming DALI-2: |
nein |
| LED rated current at constant current: |
807 mA |
| Suitable for clamp mounting: |
nein |
| Suitable for platform/floor mounting: |
ja |
| Suitable for cable system: |
nein |
| Suitable for busbar mounting: |
nein |
| Suitable for truss mounting: |
ja |
| Rated life L80/B10 at 25 °C: |
75000 h |
| Flicker value Pst LM: |
0,06 |
| Distortion factor (THD): |
6,52 |
| Stroboscopic effect value SVM: |
0,09 |
| Luminous flux reduction at average service life 100,000 h at 25 °C ambient temp.: |
96 % |
| Failure rate at average service life of 100,000 h at 25 °C ambient temp. (tq): |
10 % |
| Shipping weight: |
5,50 kg
|
| Item weight: |
1,20 kg
|
| Dimensions
( Length × Width × Height ):
|
40,00 × 36,90 × 8,50 cm |
| Fassung: |
ohne |
| Lichtfarbe: |
weiß |
