| Protection class (IP): |
IP65 |
| Illuminant: |
LED nicht austauschbar |
| With illuminant: |
Ja |
| Housing colour: |
anthrazit |
| Enclosure material: |
Aluminium |
| Light colour: |
weiß |
| Suitable for number of lamps: |
1 |
| Voltage type: |
AC |
| Control gear: |
LED-Betriebsgerät stromgesteuert |
| With control gear: |
Ja |
| Without dimming function: |
Janein |
| Dimming DALI: |
nein |
| Light emission: |
direkt |
| Energy efficiency class of the permanently installed light source: |
A++, A+, A (LED) |
| Protection class: |
I |
| Colour rendering index CRI: |
80-89 |
| Connection type: |
Steckklemme |
| Rated voltage: |
220..240 V |
| Version: |
sonstige |
| Suitable for wall mounting: |
Ja |
| Suitable for ceiling mounting: |
Ja |
| Suitable for recessed mounting: |
nein |
| Suitable for surface mounting: |
Ja |
| With motion detector: |
nein |
| Number of poles: |
3 |
| Cover material: |
Glas opal |
| Suitable for pendulum suspension: |
nein |
| Suitable for light band configuration: |
nein |
| Suitable for VDU workstations according to EN 12464-1: |
nein |
| Dimming DMX: |
nein |
| Design of the grid: |
ohne |
| Dimming Mains voltage modulation: |
nein |
| Dimming phase section: |
nein |
| Dimming phase angle control: |
nein |
| Luminaire with limited surface temperature D-sign: |
nein |
| With light sensor: |
nein |
| Rated current: |
50..55 mA54..59 mA |
| Impact resistance: |
IK05 |
| Suitable for emergency lighting: |
nein |
| Wide: |
257 mm |
| Length: |
257 mm |
| Protection class (NEMA): |
sonstige |
| Conductor cross-section: |
2,5 mm² |
| Suitable for lamp wattage: |
12 W13 W |
| IFTTT support available: |
nein |
| Compatible with Amazon Alexa: |
nein |
| Compatible with Apple HomeKit: |
nein |
| Compatible with Google Assistant: |
nein |
| Radiation angle: |
extrem breitstrahlend >80°freistrahlend/diffus |
| Colour temperature: |
3000 K |
| Dimming 1-10 V: |
nein |
| Dimming DSI: |
nein |
| Dimming manufacturer-specific: |
nein |
| Dimming with push-button: |
nein |
| Dimming Touch and Dim: |
nein |
| Dimming 0-10 V: |
nein |
| Dimming GPRS: |
nein |
| Dimming LineSwitch: |
nein |
| Dimming potentiometer (device-integrated): |
nein |
| Dimming programmable: |
nein |
| Dimming RF: |
nein |
| Dimming Sine Wave Reduction: |
nein |
| Dimming Zigbee: |
nein |
| Energy efficiency class of the light source according to EU regulation 2019/2015: |
nicht relevant |
| Light distribution: |
symmetrisch |
| Wiring type: |
Abschlussgeeignet für Durchgangsverdrahtung |
| Failure rate at average service life of 50,000 h at 25 °C ambient temp. (tq): |
10 %50 % |
| Radiation angle adjustable: |
nein |
| Replaceable control gear: |
nein |
| Rated luminous flux according to IEC 62722-2-1: |
630 lm |
| Rated ambient temperature according to IEC62722-2-1: |
-20..41 °C |
| Colour consistency (McAdam ellipse): |
SDCM3 |
| Colour temperature adjustable: |
nein |
| Glow wire test according to IEC 60695-2-11: |
960 °C - 30 s |
| Height/depth: |
81 mm |
| Constant luminous flux control: |
nein |
| Luminaire with limited surface temperature "D-sign: |
nein |
| Luminous efficacy: |
49 lm/W53 lm/W |
| Luminous flux adjustable: |
nein |
| Luminous flux reduction at average service life 50,000 h at 25 °C ambient temp.: |
80 %70 % |
| Light distributor: |
ohne |
| Max. Number of luminaires Circuit breaker B16: |
218 |
| Max. Number of luminaires Circuit breaker C16: |
218 |
| Max. System performance: |
12 W13 W |
| Emergency power supply integrated: |
nein |
| Surface protection housing: |
pulverbeschichtet |
| Photobiological safety according to EN 62471: |
RG1 |
| Covering of the luminaire with thermal insulation material possible: |
janein |
| Operation via Bluetooth: |
nein |
| Glare limitation (UGR): |
22,3 |
| Dimming depending on the control gear: |
janein |
| Dimming DALI-2: |
nein |
| Rated life L70/B50 at 25 °C: |
50000 h |
| Rated life L80/B10 at 25 °C: |
50000 h |
| With air slits: |
nein |
| Shipping weight: |
3,10 kg
|
| Item weight: |
3,10 kg
|
| Dimensions
( Length × Width × Height ):
|
26,50 × 26,50 × 12,00 cm |
| Fassung: |
sonstige |
| Lichtfarbe: |
weiß |
