Niedax clamping adapter KKAT 300 NEW

Item condition: New and in original packaging

Manufacturers: Niedax#
EAN: 4013339815708
Heiz24 article number: SP5401127
TARIC: 73089059
Country of origin: DE
Category: Kabelrinnen und Tragsysteme

€ 60,26

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

21 Pcs. in the supplier warehouse

Estimated delivery time (may vary): 3 - 5 workdays (DE - foreign countries differ)

more than 21 Pcs. we can order for you

Pcs.

Clamping adapter, for 90° cantilever arrangement on T-beams with a flange width = 300 mm, including fixing accessories for mounting the cantilever on the clamping adapter, required clamping accessories on T-beams, such as 2 x GM 5030 M10 F, 2 x SK 10X... (= 8.8) and 2 x HSK..., please order separately. In general, the outriggers must be attached to the adapters first! The clamp fastening should be symmetrical and the screws as close as possible to the flange. The load capacity specifications of the outriggers to be used apply. For the clamping adapters, these load capacity specifications only apply if, in the clamping area, the surfaces of the T-props and the profile clamps are made of steel or galvanised steel. If the building surface of a clamp connection has a coat of paint, this must be removed, otherwise the load-bearing capacity is not given or guaranteed. Danger of slipping! If steel supports are provided with a fire protection coating, this must not be removed without consultation with and written approval from the client or the site management. In any case, the transfer of loads into the structure must be coordinated with the construction planning or site management. for suspended and wall cantilevers: KTCL..., KTC... for suspended and wall brackets: KTAC..., KTAL..., KTAM..., KTA... Dimensions (approx. dimensions) H x W: 198 x 400 mm Load capacity F at L/2 of the bracket: = 1.5 kN Material: Steel, hot-dip galvanised according to DIN EN ISO 1461 Flange thickness of the bracket in mm: [customer specification required]

Item information	Value
Surface protection:	feuerverzinkt
Material grade:	sonstige
Material:	Stahl
Stainless steel, pickled:	nein
Shipping weight:	1,50 kg
Item weight:	1,41 kg
Dimensions ( Length × Width × Height ):	48,00 × 28,00 × 14,00 cm
