| Protection class (IP): |
IP20 |
| Illuminant: |
LED nicht austauschbar |
| With illuminant: |
Ja |
| Housing colour: |
Aluminium |
| Enclosure material: |
Aluminium |
| Light colour: |
weiß |
| Suitable for number of lamps: |
1 |
| Voltage type: |
DC |
| Control gear: |
LED-Betriebsgerät spannungsgesteuert |
| With control gear: |
nein |
| Without dimming function: |
Ja |
| Dimming DALI: |
nein |
| Light emission: |
direkt |
| Protection class: |
III |
| Colour rendering index CRI: |
90-100 |
| Connection type: |
sonstige |
| Rated voltage: |
24 V |
| Version: |
sonstige |
| Suitable for wall mounting: |
Ja |
| Suitable for ceiling mounting: |
nein |
| Suitable for recessed mounting: |
Ja |
| Suitable for surface mounting: |
Ja |
| With motion detector: |
nein |
| Number of poles: |
2 |
| Cover material: |
Kunststoff opal |
| Suitable for pendulum suspension: |
nein |
| Suitable for light band configuration: |
Ja |
| Suitable for VDU workstations according to EN 12464-1: |
nein |
| Dimming DMX: |
nein |
| Design of the grid: |
ohne |
| Dimming Mains voltage modulation: |
nein |
| Dimming phase section: |
nein |
| Dimming phase angle control: |
nein |
| With light sensor: |
nein |
| Rated current: |
542 mA |
| Impact resistance: |
IK00 |
| Outer diameter: |
16,5 mm |
| Suitable for emergency lighting: |
nein |
| Length: |
610 mm |
| Installation width: |
20 mm |
| Installation length: |
610 mm |
| Conductor cross-section: |
0,21 mm² |
| Suitable for lamp wattage: |
13 W |
| IFTTT support available: |
nein |
| Compatible with Amazon Alexa: |
nein |
| Compatible with Apple HomeKit: |
nein |
| Compatible with Google Assistant: |
nein |
| Radiation angle: |
extrem breitstrahlend >80° |
| Colour temperature: |
3000 K |
| Dimming 1-10 V: |
nein |
| Dimming DSI: |
nein |
| Dimming manufacturer-specific: |
nein |
| Dimming with push-button: |
nein |
| Dimming Touch and Dim: |
nein |
| Dimming 0-10 V: |
nein |
| Dimming GPRS: |
nein |
| Dimming LineSwitch: |
nein |
| Dimming potentiometer (device-integrated): |
nein |
| Dimming programmable: |
nein |
| Dimming RF: |
nein |
| Dimming Sine Wave Reduction: |
nein |
| Dimming Zigbee: |
nein |
| Energy efficiency class of the light source according to EU regulation 2019/2015: |
G |
| Light distribution: |
symmetrisch |
| Wiring type: |
mit Durchgangsverdrahtung |
| Radiation angle adjustable: |
nein |
| Replaceable control gear: |
nein |
| Rated luminous flux according to IEC 62722-2-1: |
675 lm |
| Rated ambient temperature according to IEC62722-2-1: |
-5..35 °C |
| Colour consistency (McAdam ellipse): |
SDCM5 |
| Colour temperature adjustable: |
nein |
| Glow wire test according to IEC 60695-2-11: |
ohne |
| Luminaire with limited surface temperature "D-sign: |
nein |
| Luminous efficacy: |
51 lm/W |
| Luminous flux adjustable: |
nein |
| Light distributor: |
Diffusorlinse/-optik/-panel |
| Max. System performance: |
13 W |
| Surface protection housing: |
sonstige |
| Energy efficiency class spectrum: |
A bis G |
| Photobiological safety according to EN 62471: |
RG0 |
| Covering of the luminaire with thermal insulation material possible: |
nein |
| Operation via Bluetooth: |
nein |
| Dimming depending on the control gear: |
ja |
| Dimming DALI-2: |
nein |
| With air slits: |
nein |
| Shipping weight: |
0,18 kg
|
| Item weight: |
0,13 kg
|
| Dimensions
( Length × Width × Height ):
|
61,00 × 4,20 × 2,80 cm |
