Gewiss RCD 2-p, 25A, 30mA GWD4012 NEW

Item condition: New and in original packaging

Manufacturers: Gewiss
EAN: 8011564824126
Heiz24 article number: SP5711342
TARIC: 85362010
Country of origin: PT
Category: NEW

€ 36,50

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

16 Pcs. in the supplier warehouse

Estimated delivery time (may vary): 3 - 5 workdays (DE - foreign countries differ)

more than 16 Pcs. we can order for you

Pcs.

RCCB as mains-voltage-independent residual current circuit breaker (RCCB) EN61008-1. Suitable for retrofitting of 2 additional devices and / or combinations with modules for automatic restart. The switch lever can be sealed when switched off and on or can be locked with a lever lock (order accessory separately) for a padlock. With integrated residual current indicator and fold-down inscription label. Connection (max): 35qmm with insulated plug-in protection. The connection screws can be provided with a sealable cover (order accessories separately).

Item information	Value
Protection class (IP):	IP20
Mounting type:	DIN-Schiene
Voltage type:	AC
Number of poles:	2
Width in units of division:	2
Frequency:	50/60 Hz
Explosion-proof:	nein
Connectable conductor cross-section solid:	35 mm²
Connectable conductor cross section stranded:	35 mm²
Rated voltage:	230 V
Rated insulation voltage Ui:	500 V
Installation depth:	72 mm
Rated current:	25 A
Pollution level:	2
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25..40 °C
Additional equipment possible:	ja
Short circuit strength (Icw):	10 kA
Rated residual current:	0,03 A
Residual current type:	A
Short time delayed type:	nein
With locking device:	nein
Selective type:	nein
Surge current resistance:	0,25 kA
Shipping weight:	0,20 kg
Item weight:	0,17 kg
Dimensions ( Length × Width × Height ):	10,30 × 4,20 × 8,20 cm
