Finder Coupling Relay 38.61.7.024.0050 1W 6A 24VDC NEW

Item condition: New and in original packaging

Manufacturers: Finder GmbH
EAN: 8012823231907
Heiz24 article number: ZD291905
TARIC: 85364900
Country of origin: IT
Category: Industrierelais

€ 16,10

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 4 - 6 Workdays (DE - foreign countries differ)

Narrow coupling relay series 38 AC + DC types are EMC
- wired
-Technical data:
-Extremely narrow 6.2 mm wide, 1 changeover contact, contact load 6 A/250 V AC, 6 A, 24 V DC Switching capacity 1,500 VA (AC1) max. Switch voltage 400 V AC Dimensions ( WxHxD) 6.2x87.9x75.6
-Data Switching relay:
-low coil power 0.17 W 8 mm creepage distance and 6 mm air gap between coil and contact therefore fulfils "Safe separation" according to VDE 0106 T 101 "Protection against dangerous body currents" mechanical power duration: 10 x 10 6 switching cycles Mains relay with DC control Approvals: CE, VDE, UL, CSA, GOST, RINA Coupling relay with tension clamp terminals Voltage: 24 V DC
-Design of the electrical connection spring-cage connection
-With removable terminals no
-Nominal current 6 A
-Dimensioned control supply voltage Us at DC 24
- 24 V
-Voltage type for actuation DC
-Drive, polarity reversed
-Switching behaviour of the drive monostable
-Number of contacts as NC contacts 0
-Number of contacts

Item information	Value
Shipping weight:	0,03 kg
Item weight:	0,03 kg
Dimensions ( Length × Width × Height ):	9,00 × 7,00 × 10,00 cm
