| Protection class (IP): |
IP20 |
| Height: |
38 mm |
| Supply voltage type: |
DC |
| Wide: |
45 mm |
| Mounting rail installation possible: |
nein |
| Design of the electrical connection: |
Federzuganschluss |
| Fieldbus connection possible via separate bus coupler: |
ja |
| Front installation possible: |
nein |
| Bluetooth radio standard: |
nein |
| Radio standard GPRS: |
nein |
| GSM radio standard: |
nein |
| UMTS radio standard: |
nein |
| Radio standard WLAN 802.11: |
nein |
| Suitable for safety functions: |
nein |
| IO-Link Master: |
nein |
| Rack mounting possible: |
nein |
| System component: |
ja |
| Supports protocol for ASI: |
nein |
| Supports protocol for AS-Interface Safety at Work: |
nein |
| Supports protocol for CAN: |
nein |
| Supports protocol for data highway: |
nein |
| Supports protocol for DeviceNet: |
nein |
| Supports protocol for DeviceNet Safety: |
nein |
| Supports protocol for EtherNet/IP: |
nein |
| Supports protocol for Foundation Fieldbus: |
nein |
| Supports protocol for INTERBUS: |
nein |
| Supports protocol for INTERBUS-Safety: |
nein |
| Supports protocol for KNX: |
nein |
| Supports protocol for LON: |
nein |
| Supports protocol for MODBUS: |
nein |
| Supports protocol for PROFIsafe: |
nein |
| Supports protocol for SafetyBUS p: |
nein |
| Supports protocol for SERCOS: |
nein |
| Supports protocol for SUCONET: |
nein |
| Supports protocol for TCP/IP: |
nein |
| Supply voltage for DC: |
15 V |
| Wall/direct mounting possible: |
nein |
| Associated equipment (Ex ia): |
nein |
| Associated equipment (Ex ib): |
nein |
| Type of digital output: |
sonstige |
| Number of digital outputs: |
1 |
| Output voltage type: |
DC |
| Output current: |
0,5 A |
| Digital outputs configurable: |
nein |
| Digital inputs configurable: |
nein |
| Explosion protection category for gas: |
ohne |
| Explosion protection category for dust: |
ohne |
| Short-circuit protection, outputs available: |
nein |
| With optical interface: |
nein |
| Permissible voltage at the output: |
20,4..28,8 V |
| Input voltage type: |
DC |
| Input current at signal 1: |
0 mA |
| Permissible voltage at the input: |
15 V |
| SIL according to IEC 61508: |
ohne |
| Performance Level according to EN ISO 13849-1: |
ohne |
| Number of HW interfaces other: |
2 |
| Supply voltage at AC 50 Hz: |
0 V |
| Supply voltage at AC 60 Hz: |
0 V |
| Shipping weight: |
0,05 kg
|
| Item weight: |
0,04 kg
|
| Dimensions
( Length × Width × Height ):
|
8,30 × 5,60 × 4,10 cm |
