Eaton (Moeller) Miniature circuit breaker B 16A, 2p FAZ-B16/2 NEW

Item condition: New and in original packaging

Manufacturers: Eaton#
EAN: 4015082787349
Heiz24 article number: SP0709769
TARIC: 85363010
Country of origin: RO
Category: Sicherungsautomaten, SHL,FI und sonst. Einbaugeräte

€ 57,32

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

Pcs.

Please note the permissible order quantity of 1 Pcs..

Miniature circuit-breaker, FAZ, 2-pole, tripping characteristic: B, rated current In: 16 A, switchgear for industrial applications and upmarket functional construction

Item information	Value
Protection class (IP):	IP20
Voltage type:	AC
Width in units of division:	2
Frequency:	50..60 Hz
Explosion-proof:	nein
Flush mounting:	nein
Connectable conductor cross-section solid:	1..25 mm²
Connectable conductor cross section stranded:	1..25 mm²
Rated voltage:	400 V
Rated insulation voltage Ui:	440 V
Installation depth:	70,5 mm
Rated current:	16 A
Release characteristics:	B
Pollution level:	2
Overvoltage category:	3
Number of fused poles:	2
Rated breaking capacity Icn according to EN 60898 at 230 V:	10 kA
Rated breaking capacity Icn according to EN 60898 at 400 V:	10 kA
Rated breaking capacity Icu according to IEC 60947-2 at 230 V:	15 kA
Rated breaking capacity Icu according to IEC 60947-2 at 400 V:	15 kA
Rated impulse withstand voltage Uimp:	4 kV
Energy limitation class:	3
Switching neutral conductor:	nein
Number of poles (total):	2
Ambient temperature during operation:	-25..75 °C
Additional equipment possible:	ja
Shipping weight:	0,24 kg
Item weight:	0,22 kg
Dimensions ( Length × Width × Height ):	8,60 × 3,70 × 7,50 cm
