| Protection class (IP): |
IP55 |
| Illuminant: |
LED nicht austauschbar |
| With illuminant: |
Ja |
| Housing colour: |
schwarz |
| Enclosure material: |
Aluminium |
| Light colour: |
weiß |
| Suitable for number of lamps: |
1 |
| Voltage type: |
AC |
| Control gear: |
LED-Betriebsgerät stromgesteuert |
| With control gear: |
Ja |
| Without dimming function: |
Ja |
| Dimming DALI: |
nein |
| Light emission: |
direkt |
| Protection class: |
II |
| Colour rendering index CRI: |
80-89 |
| Connection type: |
Schraubklemme |
| Rated voltage: |
230 V |
| Version: |
sonstige |
| Suitable for wall mounting: |
Ja |
| Suitable for ceiling mounting: |
nein |
| Suitable for recessed mounting: |
nein |
| Suitable for surface mounting: |
Ja |
| With motion detector: |
nein |
| Number of poles: |
3 |
| Cover material: |
Glas opal |
| Suitable for pendulum suspension: |
nein |
| Suitable for light band configuration: |
nein |
| Suitable for VDU workstations according to EN 12464-1: |
nein |
| Dimming DMX: |
nein |
| Design of the grid: |
ohne |
| Dimming Mains voltage modulation: |
nein |
| Dimming phase section: |
nein |
| Dimming phase angle control: |
nein |
| With light sensor: |
nein |
| Suitable for emergency lighting: |
nein |
| Wide: |
104 mm |
| Length: |
205 mm |
| Conductor cross-section: |
2,5 mm² |
| Suitable for lamp wattage: |
11 W |
| IFTTT support available: |
nein |
| Compatible with Amazon Alexa: |
nein |
| Compatible with Apple HomeKit: |
nein |
| Compatible with Google Assistant: |
nein |
| Radiation angle: |
extrem breitstrahlend >80° |
| Colour temperature: |
3000 K |
| Dimming 1-10 V: |
nein |
| Dimming DSI: |
nein |
| Dimming manufacturer-specific: |
nein |
| Dimming with push-button: |
nein |
| Dimming Touch and Dim: |
nein |
| Dimming 0-10 V: |
nein |
| Dimming GPRS: |
nein |
| Dimming LineSwitch: |
nein |
| Dimming potentiometer (device-integrated): |
nein |
| Dimming programmable: |
nein |
| Dimming RF: |
nein |
| Dimming Sine Wave Reduction: |
nein |
| Dimming Zigbee: |
nein |
| Energy efficiency class of the light source according to EU regulation 2019/2015: |
nicht relevant |
| Light distribution: |
symmetrisch |
| Wiring type: |
geeignet für Durchgangsverdrahtung |
| Radiation angle adjustable: |
nein |
| Replaceable control gear: |
ja |
| Rated luminous flux according to IEC 62722-2-1: |
850 lm |
| Rated ambient temperature according to IEC62722-2-1: |
-25..50 °C |
| Colour consistency (McAdam ellipse): |
SDCM4 |
| Colour temperature adjustable: |
nein |
| Glow wire test according to IEC 60695-2-11: |
650 °C - 30 s |
| Height/depth: |
143 mm |
| Constant luminous flux control: |
nein |
| Luminaire with limited surface temperature "D-sign: |
nein |
| Luminous efficacy: |
89 lm/W |
| Luminous flux adjustable: |
nein |
| Light distributor: |
Diffusorlinse/-optik/-panel |
| Max. System performance: |
9,5 W |
| Emergency power supply integrated: |
nein |
| Surface protection housing: |
unbehandelt |
| Highest energy efficiency class of the replaceable light source: |
E |
| Covering of the luminaire with thermal insulation material possible: |
nein |
| Operation via Bluetooth: |
nein |
| Dimming depending on the control gear: |
nein |
| Dimming DALI-2: |
nein |
| Rated life L70/B50 at 25 °C: |
100000 h |
| Rated life L80/B10 at 25 °C: |
50000 h |
| Rated life L90/B10 at 25 °C: |
25000 h |
| With air slits: |
nein |
| Shipping weight: |
0,68 kg
|
| Item weight: |
0,68 kg
|
| Dimensions
( Length × Width × Height ):
|
20,50 × 11,00 × 16,00 cm |
| Fassung: |
sonstige |
| Lichtfarbe: |
weiß |
