ABB Stotz S&J RCD circuit breaker pro M Compact F204A-25/0.03 NEW

Item condition: New and in original packaging

Manufacturers: ABB
EAN: 8012542783404
Heiz24 article number: SP0641458
TARIC: 85363030
Country of origin: IT
Category: Sicherungsautomaten, SHL,FI und sonst. Einbaugeräte

€ 41,07

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

10 Pcs. in the supplier warehouse

Estimated delivery time (may vary): 3 - 5 workdays (DE - foreign countries differ)

more than 10 Pcs. we can order for you

Pcs.

Residual current circuit breakers (RCCBs) provide personal and property protection as well as protection against electrically ignited fires in accordance with DIN VDE 0100-410 and DIN VDE 0100-530. The residual current circuit breakers of the F200 series guarantee protection for sinusoidal AC currents and pulsating currents with a smooth DC residual current component of up to 6 mA to earth. As well as fault protection (protection in case of indirect contact), additional protection (with I?n = 30 mA) and fire protection (with I?n = 300 mA). They comply with the product standards IEC/EN 61008-1, 61008-2-1, 61543 (VDE 0664 10, 11, 30) and for F200 A to 100 A UL 1053. Areas of application are domestic, commercial and industrial. The extensive range of accessories offers you everything you need for your installation tasks. Numerous approvals make the F200 fit for worldwide use.

Item information	Value
Protection class (IP):	IP2X
Mounting type:	DIN-Schiene
Voltage type:	AC
Number of poles:	4
Width in units of division:	4
Frequency:	50/60 Hz
Explosion-proof:	nein
Connectable conductor cross-section solid:	25 mm²
Connectable conductor cross section stranded:	25 mm² 0..25 mm²
Rated voltage:	400 V
Rated insulation voltage Ui:	500 V
Installation depth:	69 mm
Rated current:	25 A
Pollution level:	2
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25..55 °C
Additional equipment possible:	ja
Short circuit strength (Icw):	1 kA
Rated residual current:	30 A 0,03 A
Residual current type:	A
Short time delayed type:	nein
With locking device:	ja
Selective type:	nein
Surge current resistance:	0,25 kA
Shipping weight:	0,40 kg
Item weight:	0,36 kg
Dimensions ( Length × Width × Height ):	9,60 × 8,20 × 7,80 cm
