ABB Stotz S&J Circuit breaker 10kA 16A C 3p S203M-C16 NEW

Item condition: New and in original packaging

Manufacturers: ABB
EAN: 4016779550451
Heiz24 article number: SP0644268
TARIC: 85362010
Country of origin: DE
Category: Sicherungsautomaten, SHL,FI und sonst. Einbaugeräte

€ 81,49

incl. 19% VAT , plus

Choose tax zone / country of delivery

Available for immediate order
Estimated delivery time (may vary): 3 - 5 Workdays (DE - foreign countries differ)

27 Pcs. in the supplier warehouse

Estimated delivery time (may vary): 3 - 5 workdays (DE - foreign countries differ)

more than 27 Pcs. we can order for you

Pcs.

The automatic circuit breakers of the S 200 M series protect cables and lines against overload and short-circuit in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN60947-2 and UL1077 and CSA 22.2 No. 235. Their patented connection terminal ensures simple and safe contacting and handling by means of a pressure plate. For better visibility when wiring, the connection opening for cables is above the connection opening for the phase bar. Conductor cross-sections of up to 35 mm² can be connected directly to the unit via the terminal block with insulation in protection class IP20. The extensive range of accessories offers you everything you need for your installation tasks. Numerous approvals make the S 200 M fit for worldwide use. Each unit is subjected to three intensive tests for quality and performance before delivery.

Item information	Value
Protection class (IP):	IP20
Voltage type:	AC/DC
Width in units of division:	3
Frequency:	50..60 Hz
Explosion-proof:	nein
Flush mounting:	nein
Connectable conductor cross-section solid:	0,75..35 mm²
Connectable conductor cross section stranded:	0,75..25 mm²
Rated voltage:	400 V
Rated insulation voltage Ui:	440 V
Installation depth:	69 mm
Rated current:	16 A
Release characteristics:	C
Pollution level:	3
Overvoltage category:	3
Number of fused poles:	3
Rated breaking capacity Icn according to EN 60898 at 230 V:	10 kA
Rated breaking capacity Icn according to EN 60898 at 400 V:	10 kA
Rated breaking capacity Icu according to IEC 60947-2 at 230 V:	25 kA
Rated breaking capacity Icu according to IEC 60947-2 at 400 V:	15 kA
Rated impulse withstand voltage Uimp:	4 kV
Energy limitation class:	3
Switching neutral conductor:	nein
Number of poles (total):	3
Ambient temperature during operation:	-25..55 °C
Additional equipment possible:	ja
Shipping weight:	0,40 kg
Item weight:	0,38 kg
Dimensions ( Length × Width × Height ):	5,80 × 9,20 × 8,00 cm
